An AI-powered 3D orthodontic configurator that lets clinicians design, manipulate, and 3D-print custom brackets — directly from patient scans. From screen to mouth, in minutes.
Conversion Rate
Improvement
Sales Cycle
Acceleration
Distributor
Engagement Lift
New Product
Adoption Rate
| Company Revenue | Estimated Additional Revenue |
|---|---|
| $5M annual revenue | $500k – $1.2M |
| $10M annual revenue | $1M – $3M |
| $25M annual revenue | $3M – $8M |
Growth driven by improved distributor conversion, better product understanding by clinics, higher engagement during product evaluation, and faster procurement decisions.
Orthodontic products are complex and difficult to present effectively using static visuals or traditional catalogs. This often leads to low clarity, slower decision making, and reduced confidence among clinics and distributors. The client needed a more interactive and intuitive way to simplify product understanding and improve engagement.
Full manipulation panel with bracket prescription, treatment method selection, torque & angulation controls, and multi-view camera system.
Select individual brackets, move and rotate with sub-millimeter precision. Linear and rotational movement controls for perfect positioning.
Numbered tooth identification with realistic metal bracket rendering. Toggle between existing and predicted tooth positions.
Separate arch views for detailed bracket inspection. Mirror bracket heights and visualize contours, ridges, and collision data.
Load patient orthodontal scans (mandibular, maxillary, or both) directly from STL files with automatic orientation detection.
Auto-place brackets with precise torque & angulation values based on MBT prescription. Click any tooth to manually adjust.
Toggle between existing and predicted tooth positions. Visualize treatment outcomes before manufacturing begins.
Sub-millimeter linear and rotational bracket adjustments. Bracket move/rotate sensitivity slider for fine-tuned positioning.
Built-in Torque & Wires analysis, IPR calculations, Bolton Analysis, Occlusal Collisions, and Bracket Collisions detection.
Auto-generate 3D printable bracket segments organized by FDI quadrant. Export ready-to-print files with base curvature optimization.
Front, right, left, top, bottom views plus open/close jaw controls. Full 360° inspection of every bracket and tooth.
Multiple bracket collections, slot width/depth configuration, and per-tooth bracket add/delete with quadrant selection.
Toggle bracket heights, height presets, marginal ridges, contours, 3-tooth views, and mirror bracket height tools.
The final solution delivers a powerful digital platform that transforms orthodontic product visualization. By combining precise dental modeling with real-time interaction, the configurator provides orthodontists and distributors with a far more intuitive way to understand and evaluate bracket products. This positions the client at the forefront of digital transformation in orthodontic product presentation.
The configurator goes beyond visualization. An integrated analysis suite gives clinicians diagnostic-grade tools right inside the design environment.
“The configurator has transformed how we present our products making complex dental concepts easy to understand and significantly improving engagement with our distributors and clinics.”
— Michael Carter
